Synology 0 TB FS6400 NAS server, Black
- USB 3.2 Typ-A, Ethernet (RJ45)
- DDR4 ECC R-DIMM
Show all specificationsHide specifications
General information
| Part number | hs2422 |
| manufacturer | Synology |
| Model name | FS6400 |
| Product type / category | NAS server |
| Individual features | 24 bays for 2.5’ SAS HDD/SSD and SATA SSD drives |
| Product link | https://www.synology.com/de-de/products/FS6400 |
| Manufacturer part no. | FS6400 |
| EAN code | 4711174722730 |
Material and color
| Main material / case | Metal |
| Main color / manufacturer color name | Black |
Memory
| Memory size | 32 GB |
| Maximum expansion (manufacturer's specification) | 512 GB |
| Memory type / technology | DDR4 ECC R-DIMM |
Mass storage
| Storage capacity | 0 TB |
Connections overview
| Connections (device) | USB 3.2 Typ-A, Ethernet (RJ45) |
| Specifications of connections | Gigabit Ethernet (1 Gbit/s), Gigabit Ethernet (10 Gbit/s) |
Connections
| USB-A | 2 |
| USB-A specifications | USB 3.2 Gen 1 (5 Gbit/s) |
| Ethernet (RJ45) | 4 |
| Ethernet (RJ45) specifications | Gigabit Ethernet (1 Gbit/s), Gigabit Ethernet (10 Gbit/s) |
| Ethernet (RJ45): additional description | 2x Ethernet (RJ45) 1 Gbit/s, 2x Ethernet (RJ45) 10 Gbit/s |
Packaging content
| Box content (general) | Operating manual, Power cable |
| Additional content | power supply unit |
Dimensions and weight
| Device width | 43,05 cm |
| Device hight | 8,8 cm |
| Depth / thickness of the device | 69,2 cm |
| Net weight | 17,26 kg |
| Device dimensions | 43,05 cm x 8,8 cm x 69,2 cm |
Show whole descriptionHide item description
Synology Enterprise NAS FlashStation FS6400 24bay, without hard disc
High-Performance 24-Bay All-Flash NAS
The FS6400 is a high-performance all-flash NAS for IO-intensive and latency-sensitive applications.
- Processor: Two Intel Xeon Silver 8-Core CPUs
- Memory: 32 GB DDR4 ECC RAM (expandable to 512 GB)
- Drive bays: 24x 2.5" SSDs, expandable to 72 with RX2417sas
- Network: 2x Ethernet (RJ45) 1 Gbit/s, 2x Ethernet (RJ45) 10 Gbit/s with failover and link aggregation
- Expansion: 2x PCIe 3.0 x8 slots
Performance
- over 240,000 4K random write IOPS
- Ideal for real-time analyses, OLTP and business-critical databases
Features
- RAID F1 technology: Protection against simultaneous SSD failures
- Virtualisation: Support for VMware, Windows ODX, OpenStack Cinder
- Management: Easy management with Synology DiskStation Manager (DSM)
The FS6400 offers high performance, flexibility and security for demanding enterprise applications.
Show warranty and servicesHide warranty and services
Warranty and services
| Duration and type of warranty | 5 years bring-in warranty |
